2618A aluminum plate sheet for Aerospace defence components
Aluminium Alloy 2618A ( Aluminum 2618) is a high strength aluminium alloy. Alloy 2618 (2618A) has good machinability and is fair resistance to atmospheric attack. Aluminium Alloy 2618A (Aluminum 2618) is typically used in aerospace and defence components.It is commonly used for pistons and rotating aircraft parts due to it's ability to work in higher temperature applications. 2618 is also used in high performance autosport applications. Standards : ASTM B209 / ASME SB209 • Dimensions:- ASTM, ASME, and API • Grade: Aluminium Alloy 2011 (UNS A92011), Aluminium Alloy 2014 (UNS A92014), Aluminium Alloy 2017 (UNS A92014), Aluminium Alloy 2017A (UNS AA2017A), Aluminium Alloy 2618 (UNS A92618), Aluminium Alloy 2024 (UNS A92024). • Temper: O, F, H12, H14, H16, H18, H19, H22, H24, H26, H32, H34, H36, H38, H111, H112, H321, T3, T4, T5, T6, T7, T351, T451, T651, T851 • Thickness : 0.2~300mm • Width : 500~2500mm • Length:- 500~10000mm • Form: Bright, polished, hair line, brush, sand blast, checkered, embossed, etching, etc • Processing: Cutting, Forming Drilling / Machining, Grinding, Testing
Overview
AL 2618 has excellent machining characteristics. The heat treated (aged) condition will allow machining to a smoother finish than is the case for annealed or water quenched conditions
2618A aluminum alloy material is an Al-Cu-Mg-Fe-Ni series alloy that can be strengthened by heat treatment. Due to its low silicon content, its thermal strength is relatively high, and it has high plasticity in hot state. The corrosion resistance of the alloy is acceptable. Machinability is good. For the manufacture of internal combustion engine pistons and complex forgings that work at high temperatures, such as compressor impellers, blower impellers, etc.
2618 aluminum alloy has high strength and good machinability, but poor corrosion resistance. Mainly used in rivets, general mechanical parts, aircraft, ships, transportation, building structural parts, transportation structural parts, propeller components and accessories
Other Aluminum copper alloys─2000 series: 2A10, LY10, 2A11, LY11, 2A12, LY12, 2B11, LY8, 2B12, LY9, 2A16, LY16, 2B16, 2A17, LY17, 2011, 2014, 2017, 2017A, 2024, 2117, 2218, 2219, 2618, 2A14, 2A50, 2B50, 2A70
Key features :
High strength
High fatigue resistance
Low residual stress
High machining accuracy
High toughness
Technical Details and Specifications
Technical description and tables retained from the original aluminum product record.
AL 2618 has excellent machining characteristics. The heat treated (aged) condition will allow machining to a smoother finish than is the case for annealed or water quenched conditions
2618A aluminum alloy material is an Al-Cu-Mg-Fe-Ni series alloy that can be strengthened by heat treatment. Due to its low silicon content, its thermal strength is relatively high, and it has high plasticity in hot state. The corrosion resistance of the alloy is acceptable. Machinability is good. For the manufacture of internal combustion engine pistons and complex forgings that work at high temperatures, such as compressor impellers, blower impellers, etc.
2618 aluminum alloy has high strength and good machinability, but poor corrosion resistance. Mainly used in rivets, general mechanical parts, aircraft, ships, transportation, building structural parts, transportation structural parts, propeller components and accessories
Other Aluminum copper alloys─2000 series: 2A10, LY10, 2A11, LY11, 2A12, LY12, 2B11, LY8, 2B12, LY9, 2A16, LY16, 2B16, 2A17, LY17, 2011, 2014, 2017, 2017A, 2024, 2117, 2218, 2219, 2618, 2A14, 2A50, 2B50, 2A70
Key features :
High strength
High fatigue resistance
Low residual stress
High machining accuracy
High toughness
2618 aluminum alloy composition
| Cu | Mg | Mn | Fe | Si | Zn | Ti | Ni | Zr | Other | Al |
| 1.9~2.7 | 1.3~1.8 | – | 0.9~1.3 | 0.1~0.25 | 0.10 | 0.04～0.10 | 0.9～1.2 | – | 0.15 | Remainder |
2618A Aluminium Alloy Sheets, Plates & Coils Applications and Uses:- 1. Automotive Industries 2. Building Construction Industries 3. Electrical Industries 4. General Engineering Application 5. Aerospace Application 6. Transport 7. Packaging 8. Renewable Energy
