Good Formability 3003 H22 H14 5052 Aluminium Metal Plates 1100 Flat Aluminum Sheet Plate
3003 Aluminum Sheet Features ♦ Alloy: 3003 ♦ Temper: H14, H16, H18, H22, H24, H26, O ♦ Thickness(mm):0.25-10 ♦ Width(mm):800-2200 ♦ This series aluminum sheet is anticorrosive and its production technology is good. ♦ The main ingredient in it is manganese element and the content is between 1.0% and 1.5%. 3000 Aluminum Sheet Applications As a result of its good property in anti-corrosion, this series aluminum sheet is commonly used in moist environments like air conditioners, refrigerators, at the bottom of cars, etc. 3000 series aluminum sheet is approx 20% stronger than the 1000 series, has great workability and may be deep drawn, spun, welded or brazed. The 3000series aluminum sheet is widely used for general purposes. The Alloy are including the AA3003, AA3004, AA3005, AA3102, AA3105, Temper O, H14, H18, H24, H26, H111, H112, F, From thickness 0.2mm-350mm, width 500mm-2300mm, length 500mm-110000mm. With Plain, five bar, stucco, diamond, or mirror surface process, Or coated with PE, PVDF, BRUSH etc. There is (CC) cold rolling and (DC) hot rolling Line. 3003 Aluminum Sheet Approx. 20% higher strength than the 1100 series, but retaining an excellent workability rating. May show some slight discoloration when anodized, but reacts well to mechanical and organic finishings. 3003 is easily welded and brazed, but solder is limited to the torch method. Like 1100, tends to be “gummy” when machined. Non-heat treatable.Typical applications include food and chemical equipment, appliance components, truck and trailer roofing, heat exchangers, and lawn furniture components
Overview
Good Form-ability 3003 H22 H14 aluminum sheet 5052 aluminium metal plates 1100 flat aluminum sheet plate
3003 aluminum sheet Designed for sheet metal work, fuel tanks, and other applications that require a slightly higher strength than 1100 series aluminum.
The 3003 aluminum sheet is a pure aluminum that is used commercially. It’s moderately strong and can resist corrosion. Although it’s not heat treatable, it can be easily welded. It can also be formed using hot working and cold working methods. It is one of the alloys that have great machinability. When being forged with heat, it’s best for the temperature to range between 950 degrees and 500 degrees Fahrenheit. It’s best to use a filler rod like the AL 4043 when welding together 3003 aluminum with alloys like 5052, 6062 and 6061.
Technical Details and Specifications
Technical description and tables retained from the original aluminum product record.
Good Form-ability 3003 H22 H14 aluminum sheet 5052 aluminium metal plates 1100 flat aluminum sheet plate
3003 aluminum sheet Designed for sheet metal work, fuel tanks, and other applications that require a slightly higher strength than 1100 series aluminum.
The 3003 aluminum sheet is a pure aluminum that is used commercially. It’s moderately strong and can resist corrosion. Although it’s not heat treatable, it can be easily welded. It can also be formed using hot working and cold working methods. It is one of the alloys that have great machinability. When being forged with heat, it’s best for the temperature to range between 950 degrees and 500 degrees Fahrenheit. It’s best to use a filler rod like the AL 4043 when welding together 3003 aluminum with alloys like 5052, 6062 and 6061.
This aluminum grade can also be easily cold worked and has annealing capabilities, which should be done at 775 degrees Fahrenheit either during or after cold working. Afterward, air cooling should be allowed. The conductivity of 3003 alloys is 40 percent of copper.
The reason this metal is widely used is because it is affordable and strong. Compared to the 1100 series of alloys, 3003 aluminum is 20 percent stronger. This is due to it being integrated with 1.20 percent manganese. It is considered a pure aluminum and is frequently used in various applications, such as for storage tanks, tool boxes, walkways, truck beds, decorative trim and chemical equipment. It can also be used to create fan blades, siding, trailer components, kitchen equipment, cooking utensils and for signage applications.
3003 aluminum has a lot of great characteristics that make it a popular choice. Other than being weldable and corrosion-resistant, it also has a surface that has a highly polished finish, making it an attractive choice. Although thin, it cannot be bent easily, instead requiring special tools to do so
Aluminum alloy plate Sheet 3003 H14 Bare is an excellent choice for chemical equipment and general sheet metal projects due to its superior corrosion resistance and good workability. Aluminum 3003 H14 bare sheet works well in fabrication and decorative architectural uses because it is highly workable, formable, and weldable, while being capable of withstanding outdoor weather
Alloy 3003 is fairly low strength but it can be hardened to a significant degree by cold working, enabling a series of “H” tempers. Alloy 3003 is also produced as a bright finish treadplate (also known as chequer plate) with industrial and decorative applications.
3003-H14 Aluminum alloy plate is alloyed with 1.20% manganese, which increases the strength of 3003 over commercially pure aluminum (1100 series).3003 has excellent workability, weldability, and good corrosion resistance
3003 Aluminum is one of the most widely used of all aluminum alloys. It is a general purpose aluminum, with moderate strength, good workability and weldability, and excellent corrosion resistance. 3003 is a non heat treatable grade, and it may be deep drawn, or spun, welded, or brazed.
Alloy Available: 1050 1060 1100 3003, 3105, 5052, 5005, 5754 5083 5182, 6061 6063 6082, 7075, 8011…
Temper: HO, H111,H12, H14, H24,H 32, H112, T4, T6, T5,T651
Surface:Mill/Emboss/Diamond/2bar/3bars/Bright
Thickness: 0.2mm to 300mm
Width: 30mm to 2300mm
Length:1000mm to 10000mm.
Aluminum stair tread sheet, Aluminum tread Brite plate,Aluminum checker plate manufacturers, Perforated aluminum sheet china,Diamond sheet manufacturers, Aluminum tread plate manufacturers
