Tank aluminum plate
Aluminum Plate from RAYIWELL MFG or RuiYi Aluminum is an excellent material for fuel tanks since it can be rolled and bent into obscure shapes, and the advantages of light weight, case of fabrication, and high resistance to corrosion.
Overview
Tank Aluminum sheet are mostly used of 5083H111 aluminum plate, 5454H111 aluminum plate, 5182H111 aluminum plate and 5754H111 aluminum plate. According to national regulations, anti-corrosion tanks made of aluminum sheet metal have a minimum tank thickness of 5mm. According to production experience, the tank body thickness of tank is mostly 7mm. Haomei Aluminum has a hot continuous rolling, the widest plate can be 2700mm, which not only greatly reduces the welding seam of aluminum alloy tanks, improve its own strength, while making the tank body more beautiful and safer.
Tanker body: The 5083H111 aluminum plate is used for the tanker body. 5083-O aluminum plate is used for the truck lid for the lids on both sides need bending. 5454H111 aluminum plates are also used for the tanker body.
Cylinder: Aluminum alloy automobile air storage cylinders feature good corrosion resistance, light weight, good economic benefits and high recycling rate. 5083 aluminum plate is widely used in making tanker cylinder.
Technical Details and Specifications
Technical description and tables retained from the original aluminum product record.
Tank Aluminum sheet are mostly used of 5083H111 aluminum plate, 5454H111 aluminum plate, 5182H111 aluminum plate and 5754H111 aluminum plate. According to national regulations, anti-corrosion tanks made of aluminum sheet metal have a minimum tank thickness of 5mm. According to production experience, the tank body thickness of tank is mostly 7mm. Haomei Aluminum has a hot continuous rolling, the widest plate can be 2700mm, which not only greatly reduces the welding seam of aluminum alloy tanks, improve its own strength, while making the tank body more beautiful and safer.
Tanker body: The 5083H111 aluminum plate is used for the tanker body. 5083-O aluminum plate is used for the truck lid for the lids on both sides need bending. 5454H111 aluminum plates are also used for the tanker body.
Cylinder: Aluminum alloy automobile air storage cylinders feature good corrosion resistance, light weight, good economic benefits and high recycling rate. 5083 aluminum plate is widely used in making tanker cylinder.
Fuel tank: With the mass production of tank trucks, problems such as how to save fuel and production cost have risen. 5052 aluminum sheet for fuel tank is energy-saving, environmentally friendly and long-lasting.
5182 aluminum is used to produce the latest high-magnesium alloy tanker which was born for the European road dangerous goods transportation agreement in recent years. Its tensile strength and elongation are relatively high.
LNG storage tank: The volume of liquefied natural gas (LNG for short) is 1/600 of the gaseous state, which makes the material requirements for LNG storage tanks higher. Aluminum alloy 5083 is used for this application.5454 aluminum sheet is one of the high Al-Mg aluminium alloy plates, it is applicable for you to manufacture tank and shipping yard. 5454 aluminum sheet is famous in transportation vehicles application as well.
The 5182 aluminum sheet is a 5000 series Al-Mg alloy with medium strength. It is a representative of aluminum alloy with corrosion resistance, good cold workability. Besides, 5182 aluminium sheet/plate also has excellent processability, which makes it widely used in automobile, shipbuilding, construction and industry.
Mechanical property of Tank aluminum sheet
| Alloy | Temper | Tensile strength | Yield strength | Elongation |
| 5083 | O/H111 | ≥275O | ≥125 | ≥15 |
| H112 | ≥275 | ≥125 | ≥12 | |
| 5052 | O/H111 | 170-215 | ≥65 | ≥16 |
| H112 | ≥190 | ≥80 | ≥7 | |
| 5754 | O/H111 | 190-240 | ≥80 | ≥16 |
| H112 | ≥190 | ≥80 | ≥7 | |
| 5454 | H32 | ≥250 | ≥180 | ≥8 |
| 5182 | O/H111 | ≥280 | ≥125 |
Dimensions of Tank aluminum sheet / aluminium Plate
| Alloy | Thickness(mm) | Width(mm) | Length(mm) |
| 5083 | 2.0-8.0 | 1000-2000 | 2000-12600 |
| 5052 | 2.0-8.0 | 1000-2000 | 2000-12000 |
| 5754 | 2.0-8.0 | 1000-2000 | 2000-12000 |
| 5454 | 2.0-8.0 | 1000-2000 | 2000-12000 |
| 5182 | 4.0-7.0 | 980-2200 | 800-9000 |
Nowadays, with the concept of lightweight cars, the traditional iron fuel tanks are gradually replaced by aluminum fuel tanks, especially heavy trucks such as trucks. Aluminum alloy tank can reduce the weight of vehicle by half, and it is not easy to rust and has a long service life. Aluminum alloy fuel tank is mostly made of 5052 aluminum plate, which is a kind of aluminum-magnesium alloy. It is widely used as antirust aluminum in daily life, and can be applied to automobile doors, hubs, fuel tanks, fenders, bottom guards, gas tanks and other parts.
Product Images
